High-Speed Pro Features







Technical Parameters

Items Technical Data
Auto Loading Length 6m/12 m
Auto Unloading Length 2/3/6 m
Loding Weight (Max.) 1000 Kg
Chuck diameter 120/160/230/350/450/550/650mm
Round Tube diameter (Min.) 10 mm
Square Tube size (Min.) 7 mm
Linear Moving Speed (Max) 100 m/min
Max Acceleration 1.0 G
Chucks Rotary Speed (Max) 80 rpm/min
Axis positioning accuracy  (mm/m) ≤0.05mm/m
Re-positioning accuracy ≤0.03mm
Bevel Cuttging Degree (Option) ±45°
